Werth QuickInspect
The modern profile projector
Highlights
- Image processing machines for fast and precise digitising of large workpieces
- Unites profile projector and measuring microscope
- Traceable measuring results via PTB length measurement standard
- Quick comparison with CAD data via Werth Bestfit
- Simulation of e.g. insertion gauges with Werth ToleranceFit (patent)
Machine Specs
- Available Measuring Sensor - Werth image processing sensor
- Fields of View - 0.8 mm x 0.6 mm up to 230 mm x 180 mm (special ranges upon request)
- Measuring range - 250 mm x 125 mm or 400 mm x 200 mm
- Maximum permissible length measurement error - down to 0.25 µm
Industry
Automotive, Medical, Aerospace, Plastics-Moulding, Electronics
Environment
Shop Floor, Gauge and Quality Laboratory
