Werth TomoScope L
Highlights
- High Accuracy Multisensor coordinate measuring machine for 3D measurements using the principle of Computed Tomography, in combination with additional sensors (tactile sensor systems, optical sensors)
- Robust granite base with integrated air bearing rotary axis
- Optional second Z-axis for collision-free operation in multisensor mode
- Grid tomography to extend the measurement area (optional)
Machine Specs
- Micro focus X-ray source - up to 300 kV
- Measuring Range - In the Image : Ø =326 mm - L =356 mm
- Measuring Range - Using Raster Tomography : Ø =470 mm - L =667 mm
- Foot Print - Depth: 1823 mm, Width: 2570 mm, Height: 1976 mm
Industry
Automotive, Medical, Aerospace, Plastics-Molding, Electronics
Environment
Gauge and Quality Laboratory, Ultra Accurate, Computed x-ray Tomography
